S60 Shuttle XL
Unparalleled Power Incredible Results
The Solis S60 Shuttle XL tractor is a top-of-the-line tractor with a 3-Cylinder Engine, 12F + 12R Synchro Shuttle Transmission, and Advanced Hydraulics. Its easy front-end loader attachment also allows you to elevate your farming ventures to a new level.
3 CYLINDER DIESEL ENGINE
HEAVY LIFT CAPACITY
12F+12R SYNCHROMESH SHUTTLE TRANSMISSION
SLEEK & STYLISH BONNET
TECHNICAL SPECIFICATION
| ITL ENGINE | |
| No. of cylinders / capacity (cc) / emissions level | 3/ 3065/ CRDi Stage V |
| After treatment system | DOC + DPF |
| Rated engine power (kw/Hp) | 43.2/58 |
| Rated engine speed | 2000 |
| Max. torque (Nm) | 250@1400 Rpm |
| Aspiration | Turbo charged |
| Intercooler | – |
| Air Cleaner | Dual Stage Dry Type |
| Block Heater | – |
| Updraft Exhaust Pipe | – |
| Downdraft Exhaust Pipe | – |
| Fuel tank capacity (L) | 72 |
| TRANSMISSION | |
| 12×12 Synchro Shuttle transmission (4WD) | – |
| Minimum forward speed | 1.3kmph |
| Maximum forward speed | 30kmph |
| 12×12 Synchro Shuttle transmission (4WD) with Creeper |
– |
| Minimum forward speed | 0.5kmph |
| Maximum forward speed | 30kmph |
| FRONT AXLE | |
| 2WD Front Axle | – |
| 4WD Front Axle | – |
| Differential Lock | Mechanical |
| 4WD Actuation | Mechanical |
| Brake Actuation | Mechanical Assist |
| PTO | |
| PTO Type | Mechanical |
| 540/540E | – |
| 540/1000 | – |
| 540/ground speed | – |
| HYDRAULIC | |
| Hydraulic pump flow (lpm) | 45 |
| Open center mechanical draft control | – |
| Top link draft sensing | – |
| Liftomatic system | – |
| Lift Capacity | 2500 KG |
| Linkage Category | II |
| Self Locking Linkages | – |
| Self Locking Linkages | 2/3 (Opt.) |
| Max. no. of Mid remotes | 2 |
| Mechanical joystick control for mid mounts with valves |
– |
| REAR HITCHES | |
| E-Mark Swinging Drawba | – |
| Cuna Type Ladder Hitch | – |
| Semi Automatic Ladder Hitch | – |
| Automatic Ladder Hitch | – |
| TRAILER BRAKES | |
| Without Trailer Brakes | – |
| Hydraulic Trailer Brakes | – |
| Dual Line Pneumatic Trailer Brakes | – |
| Tires | Radial tires |
| Cabin | including air conditioning |
| DIMENSIONS (ROPS/CAB) | |
| Wheelbase (mm) | 2225 |
| Overall Height (mm) | 2700/2500 |
| Overall Width (mm) | 1937 |
| Overall Length (mm) | 3841-4066 |
| Front Track Width (mm) | 1570 |
| Rear Track Width (mm | 1475 |
| Ground Clearance (mm) | 335 |
| Unladen Mass (Kg) | 2920 |
| Tyre Combination | 9.5×24 & 14.9×28 |
| ELECTRICALS (ROPS/CAB) | |
| Battery | 110AH 800CCA |
| Alternator | 90A/120A |
| Button Operated Battery Cut off Switch, 3 Pinsocket, Seven On Trailer Socket |
– |
| OPERATOR ENVIRONMENT | |
| Suspended platform (with ROPS) | – |
| Premium Driver seat | – |
| Tiltable & Telescopic Steering | – |
| Integrated Loader Joystick | – |
| Cabin Air Conditioning (With Cabin) | – |
