S75 (Stage V) Rops
Legendary Power Meets Timeless Performance
Experience excellence on wheels with the Solis S75 ShuttleXL. Equipped with a cutting-edge 4 Cylinder Stage V High-End Torque Engine, a precision Synchro Shuttle Transmission, an Advanced Hydraulic Lifting Capacity for heavy-duty tasks, the state-of-the-art S Command Centre for effortless operation, and a range of Multiple Tyre Options to suit your needs. Elevate your farming game with Solis S75!
4 CYLINDER STAGE V HIGH END TORQUE ENGINE
ADVANCED HYDRAULIC LIFT CAPACITY
SYNCHRO SHUTTLE TRANSMISSION
SLEEK & STYLISH BONNET
TECHNICAL SPECIFICATION
| ITL ENGINE | |
| No. of cylinders / capacity (cc) / emissions level | 4/ 4087/ CRDi Stage V |
| After treatment system | DOC + DPF |
| Rated engine power (kw/Hp) | 55.9/75 |
| Rated engine speed | 2000 |
| Max. torque (Nm) | 340@1400 Rpm |
| Aspiration | Turbo charged |
| Intercooler | |
| Air Cleaner | Dual Stage Dry Type |
| Block Heater | |
| Updraft Exhaust Pipe | |
| Downdraft Exhaust Pipe | |
| Fuel tank capacity (L) | 88 |
| DEF Tank capacity (L) | |
| TRANSMISSION | |
| 12×12 Synchro Shuttle transmission (4WD) | |
| Minimum forward speed | 1.22kmph |
| Maximum forward speed | 35kmph |
| 20×20 Synchro Shuttle transmission (4WD) with Super Creeper |
|
| Minimum forward speed | 0.25kmph |
| Maximum forward speed | 40kmph |
| FRONT AXLE | |
| 4WD Front Axle | |
| Differential Lock | Mechanical |
| 4WD Actuation | Electro Hydraulic |
| Brake Actuation | Hydraulic Assisted |
| PTO | |
| PTO Type | Mechanical |
| 540/540E | |
| 540/1000 | |
| 540/ground speed | |
| HYDRAULIC | |
| Hydraulic pump flow (lpm) | 65 |
| Draft Control | |
| Liftomatic system | |
| Lift Capacity | 2500 Kg / 3000 Kg (O) |
| Linkage Category | II |
| Self Locking Linkages | O |
| Max. no. of rear remotes | 2/3 (O) |
| Max. no. of Mid remotes | O |
| Mechanical joystick control for mid mounts wth valves |
1 (O) |
| OPTIONAL TYRE COMBINATIONS | |
|
Bias Tyres (4WD
|
12.4*24 |
| 18.4*30 | |
|
Radial Tyres (4WD)
|
280/85R24 & 420/85R30 |
| 320/85R24 & 460/85R30 | |
| 320/70R24 & 480/70R30 | |
| 360/85R24 & 460/85R30 | |
| REAR HITCHES | |
| E-Mark Swinging Drawbar | |
| Semi Automatic Ladder Hitch | |
| Automatic Ladder Hitch | |
| Cuna Type Ladder Hitch | |
| TRAILER BRAKES | |
| Without Trailer Brakes | |
| Hydraulic Trailer Brakes | |
| Dual Line Pneumatic Trailer Brakes | |
| Tires | Radial tires |
| Cabin | including air conditioning |
| DIMENSIONS (ROPS/CAB) | |
| Wheelbase (mm) | 2350 |
| Overall Height (mm) | ROPS: 2500 – 2730 Cab: 2490 – 2650 |
| Overall Width (mm) | ROPS: 2000 – 2050 Cab: 2050 – 2080 |
| Overall Length (mm) | ROPS: 4005 – 4230 Cab: 3915 – 4140 |
| Front Track Width (mm) | 1650-1850 |
| Rear Track Width (mm) | 1500-1700 |
| Ground Clearance (mm) | 300-420 |
| Unladen Mass (Kg) | ROPS: 3550 – 3720 CAB: 3825 – 4245 |
| Tyre Combination | 11.2×24 & 16.9×30 |
| ELECTRICALS (ROPS/CAB) | |
| Battery | 130AH 800CCA |
| Alternator | ROPS: 90A / Cab: 120A |
| Button Operated Battery Cut off Switch, 3 Pinsocket, Seven On Trailer Socket |
|
| OPERATOR ENVIRONMENT | |
| Suspended platform (with ROPS) | |
| Premium Driver seat | |
| Tiltable & Telescopic Steering | |
| Integrated Loader Joystick | |
| Cabin Air Conditioning (With Cabin) | |
