Solis S 50 Shuttle XL (Stage V)
TOUGH IS JUST WHAT IT IS
Maximizing output with exceptional performance, SOLIS S 50 Stage V showcases toughness on the field like a perfect farming professional. Fully equipped with comfortable and user-friendly features for all climatic conditions, SOLIS S 50 amplifies productivity with great efficiency. Known for its high back up torque and high lifting capacity of up to 2500 kg, SOLIS S 50 Stage V is fully equipped with a spacious cabin to enhance the driver’s comfort. Taking productivity and functionality several notches higher, this strong and sturdy tractor with auto hitch feature delivers increased operational output.
3 CYLINDER DIESEL ENGINE
HEAVY LIFT CAPACITY
12F+12R SYNCHROMESH TRANSMISSION
EASY FRONT AND LOADER ATTACHMENT
TECHNICAL SPECIFICATION
| ITL ENGINE | ||||
| No. of cylinders / capacity (cc) / valves / emissions level | 3/ 3065/ CRDi Stage V | |||
| After treatment system | DOC + DPF | |||
| Rated engine power (kw/Hp) | 37.3/50 | |||
| Rated engine speed | 2000 | |||
| Max. torque (Nm) | 215@1400 Rpm | |||
| Aspiration | Turbo charged | |||
| Intercooler | Yes | |||
| Air Cleaner | Dual Stage Dry Type | |||
| Updraft Exhaust Pipe | Yes | |||
| Downdraft Exhaust Pipe | – | |||
| Fuel tank capacity (L) | 72 | |||
| TRANSMISSION | ||||
| 12×12 Synchro Shuttle transmission (4WD) | Yes | |||
| Maximum forward speed | 30kmph | |||
| Minimum forward speed | 1.3kmph | |||
| FRONT AXLE | ||||
| 2WD Front Axle | Yes | |||
| 4WD Front Axle | – | |||
| Differential Lock | Mechanical | |||
| 4WD Actuation | Mechanical | |||
| Brake Actuation | Mechanical Assist | |||
| PTO | ||||
| PTO Type | Mechanical | |||
| 540/540E | Yes | |||
| 540/1000 | – | |||
| 540/1000 | – | |||
| HYDRAULIC | ||||
| Hydraulic pump flow (lpm) | 45 | |||
| Open center mechanical draft control | Yes | |||
| Top link draft sensing | Yes | |||
| Liftomatic system | – | |||
| Lift Capacity | 2500 KG | |||
| Linkage Category | ll | |||
| Max. no. of rear remotes | 2/3 (0) | |||
| Max. no. of Mid remotes | 2 | |||
| Mechanical joystick control for mid mounts with valves | – | |||
| REAR HITCHES | ||||
| E-Mark Swinging Drawba | Yes | |||
| TRAILER BRAKES | ||||
| Without Trailer Brakes | Yes | |||
| Tires: | – Radial tires |
| Cabin | – Incl. air conditioning |
| Solis front loader | – Parallel guide – 800 kg lifting capacity (with standard bucket ) – 3rd control circuit – Available attachments: bucket, pallet fork, grab bucket, 4 in 1 bucket |
| DIMENSIONS | ||||
| Wheelbase (mm) | 2225 | |||
| Overall Height (mm) | 2690/2480 | |||
| Overall Width (mm) | 1840-1880 | |||
| Overall Length (mm) | 3825-4055 | |||
| Front Track Width (mm) | 1570 | |||
| Rear Track Width (mm) | 1450 | |||
| Ground Clearance (mm) | 310 | |||
| Unladen Mass (Kg) | 2870 | |||
| Tyre Combination | 9.5×20 & 13.6×28 | |||
| ELECTRICALS | ||||
| Battery | 110AH 800CCA | |||
| Alternator | 90A/120A | |||
| Button Operated Battery Cut off Switch, 3 Pinsocket, Seven On Trailer Socket |
Yes | |||
| OPERATOR ENVIRONMENT | ||||
| Suspended platform (with ROPS) | Yes | |||
MAJOR APPLICATIONS
Known for its over the top lifting capacity, the ultra-efficient SOLIS S 50 Stage V is highly competent and works wonders on your farm. The superior functionality ensures excellent performance in every terrain and weather condition, boosting your productivity. Engineered with a high back-up torque, this power professional is capable of carrying heavy loads without compromising your comfort and safety. It is also helpful in other farming applications like ploughing, tilling and grass cutting, actualizing all your dreams to reality.
